API 5L Line Pipe

API Pipe

Size:1/8" ～28"
Thickness:sch10, sch20, sch30, std, sch40, sch60, xs,
sch80, sch100, sch120, sch140, sch160, xxs
Standard:ASME B36.10
Material:API API 5L GrB API 5CT X42-X80



Line Pipe Physical Properties
API 5L Grade	Yield Strength min. (ksi)	Tensile Strength min. (ksi)	Yield to Tensile Ratio (max.)	Elongation min. %
A	30	48	0.93	28
B	35	60	0.93	23
X42	42	60	0.93	23
X46	46	63	0.93	22
X52	52	66	0.93	21
X56	56	71	0.93	19
X60	60	75	0.93	19
X65	65	77	0.93	18
X70	70	82	0.93	17
X80	80	90	0.93	16

API 5L line pipe, Line Pipe Physical Properties, 5L Steel Pipe Pipe Line
